XiangShan

XiangShan (香山) is an open-source high-performance RISC-V processor project.

中文说明在此。

Documentation

XiangShan's documentation is available at docs.xiangshan.cc.

The microarchitecture documentation on docs.xiangshan.cc is currently outdated for the latest version (Kunminghu). An updated version is in progress.

XiangShan User Guide has been published separately. You can find it at XiangShan-User-Guide/releases.

Publications

MICRO 2022: Towards Developing High Performance RISC-V Processors Using Agile Methodology

Our paper introduces XiangShan and the practice of agile development methodology on high performance RISC-V processors. It covers some representative tools we have developed and used to accelerate the chip development process, including design, functional verification, debugging, performance validation, etc. This paper is awarded all three available badges for artifact evaluation (Available, Functional, and Reproduced).

Paper PDF | IEEE Xplore | BibTeX | Presentation Slides | Presentation Video

Follow us

Wechat/微信：香山开源处理器

Zhihu/知乎：香山开源处理器

Weibo/微博：香山开源处理器

You can contact us through our mailing list. All mails from this list will be archived here.

Architecture

The first stable micro-architecture of XiangShan is called Yanqihu (雁栖湖) and is on the yanqihu branch, which has been developed since June 2020.

The second stable micro-architecture of XiangShan is called Nanhu (南湖) and is on the nanhu branch.

The current version of XiangShan, also known as Kunminghu (昆明湖), is still under development on the master branch.

The micro-architecture overview of Kunminghu (昆明湖) is shown below.

Sub-directories Overview

Some of the key directories are shown below.

.
├── src
│   └── main/scala         # design files
│       ├── device         # virtual device for simulation
│       ├── system         # SoC wrapper
│       ├── top            # top module
│       ├── utils          # utilization code
│       └── xiangshan      # main design code
│           └── transforms # some useful firrtl transforms
├── scripts                # scripts for agile development
├── fudian                 # floating unit submodule of XiangShan
├── huancun                # L2/L3 cache submodule of XiangShan
├── difftest               # difftest co-simulation framework
└── ready-to-run           # pre-built simulation images

IDE Support

bsp

make bsp

IDEA

make idea

Generate Verilog

• Run make verilog to generate verilog code. This generates multiple .sv files in the build/rtl/ folder (e.g., build/rtl/XSTop.sv).
• Refer to Makefile for more information.

Run Programs by Simulation

Prepare environment

• Set environment variable NEMU_HOME to the absolute path of the NEMU project.
• Set environment variable NOOP_HOME to the absolute path of the XiangShan project.
• Set environment variable AM_HOME to the absolute path of the AM project.
• Install mill. Refer to the Manual section in this guide.
• Clone this project and run make init to initialize submodules.

Run with simulator

• Install Verilator, the open-source Verilog simulator.
• Run make emu to build the C++ simulator ./build/emu with Verilator.
• Refer to ./build/emu --help for run-time arguments of the simulator.
• Refer to Makefile and verilator.mk for more information.

Example:

make emu CONFIG=MinimalConfig EMU_THREADS=2 -j10
./build/emu -b 0 -e 0 -i ./ready-to-run/coremark-2-iteration.bin --diff ./ready-to-run/riscv64-nemu-interpreter-so

Troubleshooting Guide

Troubleshooting Guide

Acknowledgement

The implementation of XiangShan is inspired by several key papers. We list these papers in XiangShan document, see: Acknowledgements. We very much encourage and expect that more academic innovations can be realised based on XiangShan in the future.

LICENSE

Copyright © 2020-2025 Institute of Computing Technology, Chinese Academy of Sciences.

Copyright © 2021-2025 Beijing Institute of Open Source Chip

Copyright © 2020-2022 by Peng Cheng Laboratory.

XiangShan is licensed under Mulan PSL v2.
